Head Office
Head Office Appearance
The current head office in Kusado-cho, Fukuyama, was originally opened as Fukuyama Factory in August 2008, and the head office functions have been centralized in Fukuyama factory since October 2008.
An extended building was completed in May 2015 to improve productivity and quality in manufacturing.
The address of the registered head office was changed on December 1, 2018.
Head Office
Entrance
At the entrance, we welcome our customers cheerfully.
Head Office showroom
Showroom
Looking at the current models operating in the showroom, customers can realize the real instrument under consideration more easily.
Tokyo branch also has a similar showroom.
design room
Design Room
We make our robots and products in the design room. Divided in mechanical, electrical, and soft design sections, each specialist staff desings by working together with each customer and discussing our proposed solution in response to customers’ request. For new product development, we have developed products to satisfy customers by considering the best forms and accuracy to meet the needs based on sales information.
training room
Training Room
To realize the product maintenance by customers, we provide maintenance trainings for various robots.
Our training menu varies from a 3-day standard to custom programs to meet customers’ requests.
Clean Room 1
Clean Room 1, 2
Clean Room 1 Area: About 526m2
Clean Room 2 Area: About 246m2
Cleanliness: Class 10,000
After assembling the wafer transfer robot for semiconductors and FPD glass substrate transfer robot and conducting a performance inspection and pre-shipment inspection, we make shipment to each user. The HEPA filter (99.97%) ventilates the clean room 25 times an hour.
Together with Clean Room 1 and 2, we are capable of manufacturing over 300 robots a month (when robot is converted to our standard robot, SCR series). Clean Room 2 is where parts are assembled by unit to make up robots.
Packing Room / Assembly Preparation Room
Shipping Room / Packing Room
Shipping Room / Packing Room is an area we prepare for final packing for the products finished the assembly and inspections. In our last process flow, we put products into the dedicated packages fitting to each shipping product.
A roof at the entrance is provided for delivery where large trucks can pull up alongside the building. From small products as represented by robot for semiconductors to large systems, we can deliver regardless of weather conditions.
Clean Room 3
Clean Room 3
Area: About 237m2
Ceiling height: 4m
Cleanliness: Class 10,000

Clean Room 3, new clean room located in the new building completed in May 2015 is equipped with a jib crane.
The HEPA filter (99.97%) ventilates the clean room 10 times an hour.
Clean booth
Clean Booth
Area: About 11.6m2(Outside Dimension: W2895 x L4020 x H3525)
Cleanliness: Class 1

Air circulation type clean booth installed in a clean room in March 2016 is capable of measuring with larger and a cleaner atmosphere as compared with the existing clean room. (The area and volume are increased by 1.8 times and 2.6 times.)
Conventional ULPA filter (99.999% (particle diameter of 0.1 to 0.2 µm)) is improved to ULPA+PTFE filter (99.9999% (particle diameter of 0.1 µm)).
To meet a requirement of higher cleanliness, particle measurement is performed in a class 1 clean booth aiming to manufacture reliable products.
Clean Room 4
Clean Room 4
Area: About 129m2
Ceiling height: 8.5m (Height of the crane from ground: 7m)
Cleanliness: Class 100,000

Clean Room 4, new clean room located in the new building completed in May 2015 is equipped with two overhead traveling cranes.
The HEPA filter (99.97%) ventilates the clean room 7 times an hour.
Large-sized products are manufactured with a high ceiling, estimating the total production of 10 large-sized systems a month.
Development Section
Development Section
In the Development Section, the examination of new product specifications or development of new products are conducted to meet the customer's needs.
This room is the start of many JEL new products to come.
